The AM233 / 233 model refers to a 3-pole industrial mobile socket (female connector) typically rated for high-current, single-phase, or specialized applications.
Here are the specifications for the 63A 2P+E (3 Pin) IP67 Industrial Mobile Socket (Model 233):
Technical Specifications:
Type: Mobile Socket (Female Connector/Coupling)
Rated Current: 63 Ampere
Poles: 2P+E (2 Pins + Earth)
Rated Voltage: 220V - 240V (Single Phase)
Earth Position: 6h (6 o'clock position)
IP Protection Rating: IP67 (Watertight/dust-tight)
Material: High-grade Polyamide 6 / Engineering Plastic
Color Code: Blue (indicates 200-250V range).
Features and Design:
Contacts: Nickel-plated brass for high corrosion resistance and conductivity
Cable Connection: Screwed terminal with watertight cable clamping system
Construction: Heavy-duty, designed for industrial, construction, and generator applications
Standards: Conforms to IEC 60309-1 and 60309-2.
