The Mean Well LRS-150-24 is a 156W, 24V DC enclosed switching power supply designed with a 1U low-profile form factor. It delivers 6.5A at 24V, features a 115/230V selectable input, and provides high efficiency up to 89%. Ideal for industrial, LED, and automation applications, it includes protections against short circuits, overloads, and overvoltage.
Key Specifications Model: LRS-150-24Output Voltage: 24V DCRated Current: 6.5ARated Power: 156W (154.8W - 156W)Input Voltage: 85–132VAC / 170–264VAC (switchable)Adjustable Output Range: 21.6V – 28.8V DCEfficiency: 89%Dimensions: 159 x 97 x 30 mm
Protection: Short circuit, overload, overvoltage, overtemperatureCooling: Free air convection Additional Features Compact Design: 1U Low profile (30mm height)No Load Power Certifications: IEC/EN/UL62368-1, IEC/EN60335-1Voltage Adjustment: Built-in potentiometer (+V ADJ)Indicator: LED indicator for power onTermination: Screw terminals .
